metal deck roll forming machine efficiently forms galvanized steel into high-strength deck profiles, ensuring precision, speed, and consistency for large-scale construction.WhatsApp +86 17802216114 or email bernice@hx-machinery.com.
The metal deck roll forming machine is a specialized piece of equipment designed to produce high-strength steel deck panels used in multi-story and industrial buildings. It processes galvanized coils into precisely shaped profiles that not only support heavy concrete loads but also act as permanent formwork, streamlining construction and reducing labor. With advanced automation, accurate forming, and durable build quality, this machine ensures high-volume, consistent output to meet the demands of modern structural flooring projects.
metal deck roll forming machine
metal deck roll forming machine
Formed Material
GI/GL, PPGI/PPGL
Thickness
0.5-1.5mm
Width
914mm(customized)
Decoiler
Manual decoiler(will give you as free)
Roller station
22 rows (As your requirement)
Diameter of shaft
90mm solid shaft
Material of rollers
45# steel, forging with chromium plate 0.05mm
Cutter
Cr12 Mov quenched treatment 58℃-62℃
Power
7.5+5.5KW
Control system: PLC
Automatic production of the whole machine. Can set batch, length, quantity, etc.
10-15 m/min (The speed depends on the shape of the tile and the thickness of the material.)
Why Choose Us
Designed for the demands of high-rise and commercial construction, the deck floor roll forming machine converts galvanized steel into structurally sound deck profiles with high precision. These panels serve dual purposes—as permanent formwork and load-bearing reinforcement for concrete floors. Its automated system and robust engineering maximize production efficiency while maintaining exceptional quality with every sheet.
About Us
With nearly three decades of experience, Haixing Tianjin has become a trusted name in cold forming technology, offering expertly crafted machines for roofing and construction use. Our equipment is in operation across more than 150 countries, a testament to its quality and dependability. Certified to meet CE and ISO standards, our roll forming solutions reflect the best of Chinese engineering and global quality expectations.
FAQ:
Q: What types of roof panel forming machines do you mainly produce? A: We focus on metal roof panel roll forming machines, including vertical lock seam panels, corner panels, corrugated panels, antique glazed tiles and other 20+ types of equipment, supporting customized molds.
Q: What raw materials are suitable for the machine? Thickness range? A: Mainly processed galvanized sheets, color-coated sheets, aluminum alloy sheets, material thickness can usually be adjusted according to demand.
Q: What is the production speed of the equipment? A: The standard model speed is 10-15 meters/minute, and the high-end model can reach 20 meters/minute, depending on the complexity of the pattern.
Q: Can you provide a trial video or sample? A: We can provide real-time trial videos and molded samples for delivery. If you need on-site inspection, please make an appointment to visit the factory.
Q: Is the equipment fully automatic or semi-automatic? How many people are needed to operate it? A: Standard PLC fully automatic control system, only 1-2 people are needed to operate (feeding + monitoring), and high-end models can be connected to automatic feeding racks.
Q: What is the material of the mold? What is the service life?
A: The mold is made of Cr12MOV mold steel, surface quenching treatment, and the service life can reach more than 500,000 extended meters under normal use, and it supports renovation and maintenance.
Q: Does it support customized version? How long is the mold development cycle?
A: Support customized version according to drawings, the mold development cycle is about 20-30 days (need to confirm the complexity of the drawings), and a 3D design plan can be provided first.
Q: Can the equipment voltage and frequency adapt to our country?
A: Support global voltage customization (220V/380V/415V, 50Hz/60Hz), and will be debugged according to the customer's national standards before leaving the factory.
